R48-2000e Rectifier

Emerson Rectifier Module R48-2000e Supply

AC Input

Voltage 85 VAC to 300 VAC (see figure 1) 200 VAC to 250 VAC (nominal)

Frequency 45 Hz to 65 Hz

Maximum Current 13 A

Power Factor 0.99

DC Output

Voltage -42 VDC to -58 VDC Maximum Power 2000 W @ Vout >48 VDC

Maximum Current 41.7 A @ -48 VDC, limit set point 0 to 42 A (see figure 2 for derating)

Peak Efficiency 96.5% peak

Psophometric Noise (System) <2 mV typical ; <38 dBrnc typical

Temperature Derating See Diagram (see figure 3)

Original Vertiv Emerson Rectifier Module R48-2000e Supply

Vertiv eSure R48-2000e rectifier converts standard AC supply voltages into stable nominal -48V DC voltage adjustable to the needs of the application. Emerson R48-2000e is a constant power rectifier designed with the latest patented switch-mode technology using DSP (Digital Signal Processor) functionality for efficient operation. For a higher load capacity, rectifiers can be connected in parallel and intelligent control can be added with the help of a separate controller
